CONICITÀ 1:10 / TAPER 1:10

Ø A	B	D	E	C	G	CH
20	15,8	35	3,2	30	42	6
22	17	39	3,2	37	50	6
25 - 1"	19,2	42	3,2	37	58	6
28	21,2	45	3,5	40	68	8
30	22,4	52	3,5	45	76	8
32 - 1" 1/4	24,4	52	4,2	45	76	10
35	26,4	57	4,2	50	86	10
40 - 1" 1/2	30,4	64	4,2	55	96	12
45 - 1" 3/4	34,4	75	4,5	65	106	14
50 - 2"	38,5	84	4,5	75	115	14
55 - 2" 1/4	42	94	5,5	80	130	16
60	46	105	5,5	90	140	18
65 - 2" 1/2	49,5	120	5,5	100	155	18
70	54,5	120	5,5	100	155	20
75 - 3"	57	140	5,5	120	180	22
80	62	140	5,5	120	180	22
85	64,5	160	5,5	135	205	24
90	68,5	160	5,5	135	215	24
95	72,5	180	6,5	150	225	28
100 - 4"	76,5	180	6,5	150	235	28
105	81,5	210	6,5	170	235	28
110	86,5	210	6,5	170	235	28
115	90,5	220	7,5	180	245	32
120	94	220	7,5	180	260	32

CONICITÀ 1:16 / TAPER 1:16

Ø A	B	D	E	C	G	CH
3/4	0,61	1 - 3/8	3/32	1 - 3/16	2 - 1/4	3/16
7/8	0,71	1 - 1/2	1/8	1 - 7/16	2 - 5/8	1/4
1	0,81	1 - 5/8	1/8	1 - 1/8	3	1/4
1 - 1/8	0,91	1 - 3/4	1/8	1 - 9/16	3 -3/8	1/4
1 - 1/4	1,01	2 - 1/16	5/32	1 - 3/4	3 - 3/4	5/16
1 - 3/8	1,11	2 - 1/4	5/32	2	4 - 1/8	5/16
1 - 1/2	1,22	2 - 1/2	3/16	2 - 3/16	4 - 1/2	3/8
1 3/4	1,42	3	7/32	2 - 9/16	5 - 1/4	7/16
2	1,62	3 - 5/16	1/4	3	6	1,2
2 - 1/4	1,82	4	9/32	3 - 3/8	6 -3/4	9/16
2 - 1/2	2,03	4 - 1/2	5/16	3 - 3/4	7 - 1/2	5/8
2 - 3/4	2,64	5 - 7/8	5/16	4	8 - 1/4	5/8
3	2,43	5 - 1/2	5/16	4 - 3/4	9	3/4
3 -1/40	2,64	5 - 7/8	5/16	5	9 - 3/4	3/4
3 - 1/2	2,84	6 - 1/4	5/16	5 - 5/16	10 - 1/2	7/8
3 - 3/4	3,04	7 - 1/8	5/16	5 - 7/8	11 - 1/4	7/8
4	3,25	7 - 1/2	5/16	6 - 5/16	12	1
4 - 1/2	3,79	8 - 5/8	3/8	7 - 1/8	11 - 1/4	1 - 1/8
5	4,22	9 - 1/8	7/16	7 - 1/2	12 - 1/2	1 - 1/4
